Gasoline Generator

4500W - 10000W Gasoline Generator Set

Brand: JET POWER
Power: 4500W - 10000W
Alternator with AVR
OHV Single cylinder engine
Product description: Gasoline Generator 4500W to 1000W Manual Start, Carton packing, Optional Electric start with battery, wheel kit.
INQUIRY

■ Neat and economical for classical design.
■ Advanced AVR offers over-voltage, overheated and overload protection for the generator.
■ Frame designed for better protection.
■ Oil alert system with automatic engine shut-off.
■ 13HP to 22HP gasoline engine equipped.
■ Hydraulic-Magnetic circuit breaker.
■ 25L fuel tank enables Long-time for running.
■ Large muffler for quiet operation.
■ CE,EC-II,EPA,CARB,EMC approved

Specifications:

Genset Model:		JET5500	JET6500	JET7500	JET12000E
Genset	AC Frequency (Hz)	50HZ	50HZ	50HZ	50HZ
	AC Output voltage(V)	120;220;230;240;	120;220;230;240;	120;220;230;240;	120;220;230;240;
	Rated AC Output	4500W	5000W	6000W	8500W
	Max.AC Output	5000W	5500W	7000W	10000W
	Power Factor	1	1	1	1
	DC Output ( If choose)	12V/8.3A	12V/8.3A	12V/8.3A	12V/8.3A
Engine	Engine	GE390	GE390	GE420	GE690
	Type	4-stroke OHV; Air-cooled; Gasoline Engine, (HONDA Technology)			Two-cyinder,V-twin,four-stroke,OHV Gasoline engine
	Displacement(cc)	389	389	420	688
	Starting System	Recoil or Electric	Recoil or Electric	Recoil or Electric	Electric start
	Lubrication oil	SAE 10W/30	SAE 10W/30	SAE 10W/30	CDgrade or SAE10W-30,15W-40
	Oil capacity (L)	1.1	1.1	1.1	1.9
	Compression ratio	8.0:1	8.0:1	8.0:1	9.3:1
	Bore×Stroke	88mm×64mm	88mm×64mm	90mm×66mm	2* 78MM × 72MM
	Max.Output(hp/rpm)	13/3600	13/3600	16/3600	22.1/3600
	Fuel Consumption (g/hp.h)	≤374	≤374	≤390	≤374
	Ignition System	Non-contact transistorized ignition (T.C.I)			Digital CDI with variable ignition timing
	Spark Plug	F7TC	F7TC	F7TC	F7TC
	Fuel Tank Capacity(l)	25	25	25	25
	Continuous Work(h)	10	10	10	6
	Noise Level LwA dB(A)	74	74	74	77
Standard Features	Oil Alarm	With	With	With	With
	Fuel indicator	With	With	With	With
	AC Voltmeter	With	With	With	With
	Standard Socket	With	With	With	With
	AC Circuit Breaker	With	With	With	With
	Large-capacity air filter	With	With	With	With
	Large-capacity fuel tank	With	With	With	With
	Auto voltage adjuster (AVR)	With	With	With	With
	DC Output	With	With	With	With
Packing	Dim(mm)	697X525X562	697X525X562	713X541X569	913X541X569
	Gross Weight(kg)	82	82	86	161
	20ft Container Qty	135	135	135	72
	40ft HQ Container Qty	292	292	280	150
